Лити ион нарны зай 51.2v 100ah 200ah 300ah

2024-08-27 11:02

Бүтээгдэхүүний тодорхойлолт

Нэрлэсэн хүчдэл	51.2V	51.2V	51.2V
Нэрлэсэн хүчин чадал	100А	230Ah	304AH
Эрчим хүч	5120Wh	11776Wh	15360wh
Series or Parallel Connection	16S1P	16S1P	16S1P
Хамгийн их цэнэгийн гүйдэл	100А байна	200А байна	200А байна
Charge Current (-20 to - 10 ºC)	≤0.05C	≤0.05C	≤0.05C
Санал болгож буй цэнэгийн хүчдэл	56V-57.6V	56V-57.6V	56V-57.6V
BMS цэнэглэх хүчдэлийг таслах	57.6V (3.75±0.025vpc)	57.6V (3.75±0.025vpc)	57.6V (3.75±0.025vpc)
Хүчдэлийг дахин холбоно уу	54.6V (3.34 ±0.05vpc)	54.6V (3.34 ±0.05vpc)	54.6V (3.34 ±0.05vpC)
Dimensions (L x W x H)	440*435*222mm (17.3x17.1x8.74”)	480*248*618mm	475*255*770mm
Жин	70KG with wooden packing	:116KG with wooden packing	138KG with wooden packing
Харилцааны интерфейс	RS485 (Optional)	RS485 (Optional)	RS485/CAN (Optional)
Кейсийн материал	Металл	Металл	Металл
Enclosure Protection	IP54	IP54	IP54
Хамгийн их тасралтгүй урсах гүйдэл	100А байна	200А байна	200А байна
БМС-ийн урсгалын одоогийн тасалдал	105А	230А	230А
Хүчдэлийг дахин холбоно уу	45V	45V	45V
Буулгах температур	-20 to 60ºC (-4 to 140 ºF)	-20 to 60ºC (-4 to 140 ºF)	-20 to 60ºC (-4 to 140 ºF)
Цэнэглэх температур	0 to 45ºC (32 to 113 ºF)	0 to 45ºC (32 to 113 ºF)	0 to 45ºC (32 to 113 ºF)

* Please Click Here:We Provide OEM /ODM Service !
* Quick Delivery From China.
Бид хамгийн аюулгүй литийн төмрийн фосфатын батерейг хийхээр зорьж байна.
Манай бүх батерейнууд нарийн шалгалтанд хамрагдсан бөгөөд дэлхий даяар хэрэглэхэд аюулгүй гэж баталгаажуулсан.
Манай борлуулалтын бүх лити батерейнууд нь CE, UN38.3, MSDS болон бусад тээврийн дүрэм журмыг дагаж мөрдөж, хурдан шуурхай хүргэлттэй!
Хэрэв танд бүтээгдэхүүнтэй холбоотой гэрчилгээ хэрэгтэй бол бидэнтэй холбоо барина уу!
* For additional benefits For resellers

we provide super price for you and policy, We offer one-stop solar energy storage solutions,please contact us directly and we will tell you more. Most importantly, we can provide you with professional solutions tailored to your local market.



Products Feature

1.Excellent safety performance: Safest lithium iron phosphate battery, CE BIS, MSDS, UN38.3 approved, with built-in BMS.

2.Long cycle life and deep cycle: Performs more than 6000 cycles, 6-8 times longer than lead acid battery.

3.No memory effect, highly efficient and high energy density.

4.Compact size and light weight: 1/2 size & weight of lead acid battery

5.Excellent high temperature performance

6.Low self-discharge rate: < 3% per month

7.High IP standard: IP65 Waterproof.



Програм

Манай үйлдвэр



Хүргэлт ба сав баглаа боодол

Асуулт

Q1. Do you have MOQ (Minimum Order Quantity) limit?
A: No, ALL IN ONE do not have MOQ limit, 1pc sample order or small quantity is available.

Q2. Удирдах цагийг яах вэ?
A: Standard product lead time: Samples: 3-5 days, Bulk order: 3-4 weeks.
Customized product lead time: 3-4 weeks both for sample or bulk order.

Q3. How do you ship the goods? How about the Shipping time?
A: By air door to door (6-12 days): FEDEX, UPS or DHL, suitable for urgent small order.
By sea door to door (25-50 days): suitable for bulk order.
By sea to delivery port (20-35 days): Suitable for bulk order.
By Air to airport (3-5 days): Suitable for urgent heavy package.

Q4. How to proceed with an order?
A: Firstly, providing your requirements or applications, then we will provide battery solution and quote accordingly.
Secondly, confirming the order and do the deposit for it, then we will arrange the production.

Q5. Is it available to print my logo on the product?
A: Yes. For OEM Demand please send us your logo and we will make a label for the product. For product with metal/aluminum case, logo silk-print on the case is available.
